Main Battle Tank (1989)

Norinco

ZTZ-85 (Type 85)

ZTZ-85-IIM

Based on the earlier Type 80, the Type 85 (ZTZ-85) represented a further step in the modernization of Chinese tank design towards Western practices. The Type 85 retained the general shape and configuration of the Type 80's hull but with an entirely new all-welded steel turret. This gave it a more modern look compared to its predecessors, all of which strongly resembled the Soviet T-54/55 due to their rounded cast turrets. A layer of composite armor is also added to the glacis plate and the turret front; the first Chinese tank to feature this. The Type 85 incorporated a host of equipment upgrades including a computerized fire-control system and independently stabilized sights which enable the crew to fire on the move. The Type 85 initially retained its predecessor's 105-mm rifled gun but this was later upgraded into a 125-mm smoothbore fed from an autoloader which kept the crew to just three. Its ammunition is cross-compatible with that of the T-72. A collective NBC system is also added, compared to the individual system of the Type 80. Although it was not initially adopted by the PLA, the Type 85 was exported to Pakistan, it's only export customer (some were built under license). Only later were upgraded versions taken over by the PLA although still in relatively small numbers compared to other tanks in the army's arsenal. The Type 85 also served as the basis for the Type 90 and Type 96 (ZTZ-96) tanks.

The Type 85-II and Type 85-IIA were first revealed in 1989, preceded by the prototype-only Type 85-I. These were armed with Type 83 105-mm guns. This was substituted by the Type 85 125-mm smoothbore in the Type 85-IIM which also features an image stabilized fire control system (ISFCS). Pakistani export versions are known as the Type 85-IIAP but were modified to include the 125-mm gun. A final variant is known as the Type 85-III which includes a more powerful engine as well as ERA protection. Confusingly, this variant was later known as the Type 88C and Type 96 (ZTZ-96). Earlier PLA and Pakistani variants were modernized to this standard. The Type 85-IIM was further adapted into the Type 90-II which had minor equipment and structural changes, notably the driver compartment was moved to the center of the front hull. It was used only for trial purposes but served as the basis for the Pakistani-built Al Khalid (MBT-2000) tank.

Preceded by:

ZTZ-80/88 (Type 80/88) (1988)

Succeeded by:

ZTZ-96 (1997)

Datafile

DesignZTZ-85-IIM
TypeMain Battle Tank
Year1989
Crew3
Dimensions
Length (w/Gun)6.33 m (10.28 m)
Width3.450 m
Height2.300 m
Ground Clearance0 m
Track0 m
Track on Ground0 m
Weight
Combat41,000 kg
Ground Pressure0.77 kg/cm²
SuspensionTorsion bar
Performance
Speed (Off-Road)57 km/h
Range (Off-Road)700-900 km
AmphibiousNo
Fording1.40 m (2.4 m)
Vertical Obstacle0.80 m
Trench2.70 m
Gradient60%
Powerplant
Engine1 x 730-hp
Model VR-36
FuelDiesel
Power/Weight17.80 hp/t
Armament
Main1 x 125-mm
Type 85

Smoothbore Gun
↑ 14° / ↓ -4.5° / ↔ 360°
SecondaryNone
Armor
TypeComposite
Thickness400 - 400 mm
Max Effective400 - 400 mm RHAe
Hull Upper Front400 mm
Turret Front400 mm
Production
Builtn/a
Total?
