Air Weapons

Interceptor (1956)

Sud-Ouest

Vautour

Vautour

The Sud-Ouest Vautour (Vulture) was designed as a multi-role combat aircraft capable of performing in the tactical day fighter, all-weather interceptor, and attack aircraft, the first of which was a single engine design while the others were tandem two seaters. The Vautour featured a mid-wing configuration with swept wings and two Atar turbojets mounted on underwing nacelles. Other design characteristics included a solid nose for the fighter versions (the all-weather variant with radar) and the bomber version with a glazed nose and an internal bomb bay which could even carry a tactical nuclear weapon. Ultimately, the fighter version was exported to Israel whereas the interceptor and bombers went on to enjoy lengthy service with the Armee de l'Air where they were retired until 1973. Isreali versions saw combat during the Six Day war where while some were also used for electronic warfare with ECM receivers and jammers.

Three prototypes were built for the three main roles of the SO.4050 Vautour, the first of which was the all-weather fighter which had its maiden flight on 16 October 1952. Production units were eventually renamed Vautour II and included the Vautour IIN interceptor, the IIA tactical fighter, and the IIB bomber. Israeli exports were intially composed of all production IIAs and later complemented by a number of former French IINs with the radar removed and used for attack missions.

Preceded by:

None

Succeeded by:

Mirage IV (1964)

Datafile

DesignVautour IINVautour IIB
TypeInterceptorAttack
Year19561957
Crew22
Dimensions
Length17.30 m17.65 m
Height5.100 m5 m
Wing Span15.10 m15.10 m
Wing Arean/an/a
Weight
Empty10,420 kg10,580 kg
Maximum20,810 kg20,700 kg
Wing Loading462.4 kg/m²460 kg/m²
Performance
SpeedMach 1.11,100 km/h
Ceiling15,000 m15,000 m
Range1,200-5,000 km2,275 km
Powerplant
Engine2 x Atar 101E-5
SNECMA
3,700 kgf
2 x Atar 101E-3
SNECMA
3,500 kgf
Thrust/Weight0.650.60
Sensors
RadarDRAC-32AI
-
Armament
Guns4 x 30-mm
-
Payload4,000 kg4,400 kg
Hardpoints44
AA Weapons-AN-11
AN-22
Production
Built7040
Total149
