Strategic Bomber (1951)

Boeing

B-47 Stratojet

B-47E Stratojet
B-47E

The Boeing B-47 Stratojet was the first major USAF jet engined bomber of the Cold War and the most widely produced of its kind since World War II. Sleek and modern looking with thin swept wings which mounted six turbojet engines (four mounted in two pairs with the other two in single nacelles), the B-47 formed the backbone of the Strategic Air Command's nuclear deterrance where they served with a total of 36 bomber wings many of which were on full readiness in the event war would have broken out between the superpowers. Yet despite its revolutionary design, the B-47 suffered a plethora of production difficulties which were excaberrated by political decisions which meant that the true importance of such an aircraft was not realized until the Korean War and thus the escalating tensions of the Cold War scaled up its development. Ironically for such a groundbreaking aircraft, the B-47 saw no combat as bombers although reconnaissance variants were used during the Vietnam War as well as performing clandestine missions over the Soviet Union, Eastern Europe, and China where at least one was shot down and others damaged. The final units were retired in 1965 by which time it had been replaced in the SAC by the B-52.

First flight of the XB-47 prototype took place on 17 December 1947 powered by J35 engines later replaced by J47s in the production B-47A (which were used for training and testing purposes only). The first combat variant was the B-47B with reduced nose glazing, square fin tip, underwing fuel tanks, inflight refuelling capability but also the removal of the crew ejection seats. Later, the B-47E was the most widely produced Stratojet variant with new engines, a strengthened structure, even more reduced nose glazing, a drag parachute for landings, and the reinstallation of the ejection seats. Meanwhile, major modifications of existing B-47Bs up to E standard resulted in the B-47B-II while a similar upgrade of the E versions themselves became the B-47E-II. Photo reconnaissance versions began with the RB-47B followed by the RB-47E (based on the B and E) while the RB-47H was an electronic intelligence platform and the RB-47K used for weather reconnaisance. A crew trainer was known as the TB-47B.

Preceded by:

B-29 Superfortress (1944)

Succeeded by:

B-52 Stratofortress (1955)
B-58 Hustler (1960)

Datafile

DesignB-47BB-47E
NameStratojetStratojet
TypeStrategic BomberStrategic Bomber
Year19511953
Crew33
Dimensions
Length33.48 m33.48 m
Height8.509 m8.509 m
Wing Span35.36 m35.36 m
Wing Arean/an/a
Weight
Empty35,427 kg36,631 kg
Loaded93,759 kg
Maximum90,719 kg99,791 kg
Wing Loading683.8 kg/m²752.2 kg/m²
Performance
Speed993 km/h974 km/h
Cruise Speed?796 km/h
Ceiling12,436 m11,582 m
Range6,297 km6,438 km
Powerplant
Engine6 x J47-GE-23
General Electric
2,631 kgf
6 x J47-GE-25
General Electric
2,722 / 3,266 (+) kgf
Thrust/Weight0.410.41
Armament
Guns2 x .50-in
2 x 20-mm
M24A1
Payload9,072 kg9,072 kg
AS WeaponsB28/41/47/53
M117
Mk. 15
B28/41/53
M117
Mk. 15
Production
Built3991,341
Total2,042
