Strategic Bomber (1955)

Boeing

B-52 Stratofortress

B-52H Stratofortress (USAF, 2nd Bomb Wing)
B-52H

If longevity is the ultimate measure of success, few aircraft in the history of aviation can claim being as successful as the Boeing B-52 Stratofortress, last in the line of the legendary "Fortress" series of Boeing-built bombers and currently one of the triad of US strategic bombers. Its original requirement originated as early as 1945 (while World War II was still raging) and went through various different development concepts until settling on the now-familiar massive swept-wing design with eight-engines and double-tandem undercarriage. Despite the introduction of the B-47, there was still great interest in developing the B-52, partly under the urging of the then commander of the Strategic Air Command, Curtis LeMay. The B-52 incorporated many of the technological advances introduced in the B-47, such as the large swept-wings and the engines being housed in pods under the wings. The B-52 introduced a side-by-side cockpit arrangement which replaced the fighter-style tandem cockpit found in the B-47 and also in the B-52 prototypes. The B-52 was also considerably larger than its predecessor which necessitated a redesign of airbase facilities to accommodate the new aircraft. Despite the fact that its service life was scheduled to be brief due to the emergence of new jet technologies, the B-52 slowly became the mainstay of the US Strategic Bomber Command during the Cold War to the point that it equipped well over 30 SAC wings at its peak in the 1970s when dozens of these bombers were on permanent alert around the USSR in the event of a nuclear showdown. Impressively, the entire production run of over 700 aircraft was undertaken in less than a decade. B-52s played a prominent role during the Vietnam War where they made numerous raids over North Vietnam culminating in Operation Linebacker II (1972) which led to the Paris peace talks. Despite their formidable capability for carpet bombing, 31 aircraft were lost to all causes during the war. Later variants became re-equipped with stand-off nuclear missiles. Given the immaturity of the B-1 as a conventional bomber at the time, the B-52 became the main strategic bomber in use during the Gulf War (where one aircraft set a 35-hour flight record), and saw further action in the Afghanistan and Iraq wars as well as the Libya and Syria interventions where their range enabled them to loiter over the battlefield, in effect turning them into close support aircraft (a role unlikely to have ever been envisioned by its original designers). Today, the B-52 remains in service with the USAF in wider numbers than any other strategic bomber, with an unprecedented service life deemed likely to last up to the year 2050 until replaced by the B-21 Raider.

Two prototypes were built by Boing, the XB-52 and YB-52. It was the latter which first flew on 15 April 1952, the first few production aircraft were designated B-52A but the first major variants were the B-52B and B-52C, both of which were dedicated nuclear bombers. The next generation of B-52s would feature extensive conventional bombing capabilities such as a "big belly" modification for the B-52D which gave it greater payload. Its successors, the B-52E and B-52F, had more advanced avionics and were among the first to see service in Vietnam. The final series of B-52s began with the B-52G, the most widely built version which was also the first to feature stand-off weapons capability, electronic counter-measures, as well as having a slightly revised airframe design which provided it with greater performance. B-52Gs were used extensively in the Gulf War where they were paired with the B-52H, the last variant built (and the only one which remains in service with the USAF) which differed from its predecessor mainly because of new TF33 engines: this new powerplant increased performance considerably while subsequent revisions would allow it to carry the latest range of US precision weapons. Lastly, the only major non-combat variant was the RB-52B reconnaissance aircraft.

Preceded by:

B-47 Stratojet (1951)

Succeeded by:

B-1 Lancer (1986)

Datafile

DesignB-52BB-52DB-52GB-52H
NameStratofortressStratofortressStratofortressStratofortress
TypeStrategic BomberStrategic BomberStrategic BomberStrategic Bomber
Year1955195619581961
Crew6666
Dimensions
Length47.73 m47.73 m49.02 m49.02 m
Height14.719 m14.719 m12.395 m12.395 m
Wing Span56.39 m56.39 m56.39 m56.39 m
Wing Arean/an/an/an/a
Weight
Empty74,427 kg80,657 kg76,406 kg78,354 kg
Maximum100,000 kg100,000 kg100,000 kg100,000 kg
Wing Loading269.1 kg/m²269.1 kg/m²269.1 kg/m²269.1 kg/m²
Performance
Speed1,014 km/h1,022 km/h1,022 km/h1,014 km/h
Ceiling14,417 m14,082 m14,326 m14,539 m
Range11,817 km12,082 km13,529 km18,532 km
Powerplant
Engine8 x J57-P-1W
Pratt & Whitney
5,171 kgf
8 x J57-P-19W
Pratt & Whitney
5,489 kgf
8 x J57-P-43WB
Pratt & Whitney
6,237 kgf
8 x TF33-P-3
Pratt & Whitney
7,711 kgf
Thrust/Weight0.510.490.590.72
Sensors
Radar---AN/APQ-156
Armament
Guns4 x .50-in
M3 Browning (600)
4 x .50-in
M3 Browning (600)
4 x .50-in
M3 Browning (600)
1 x 20-mm
M61A1 Vulcan (1,242)
Payload19,505 kg27,216 kg31,752 kg31,752 kg
Hardpoints--22
AS WeaponsB28/41
CBU-87/89
M117
Mk. 82/84
AGM-28
B28/41/43/61/83
CBU-87/89
M117
Mk. 82/84
AGM-28
AGM-69
AGM-84
AGM-86
AGM-142
B28/41/43/61/83
CBU-87/89
M117
Mk. 62
Mk. 82/84
AGM-28
AGM-69
AGM-84
AGM-86
AGM-129
AGM-142
AGM-154
AGM-158
B28/41/43/61/83
CBU-87/89
GBU-15
GBU-31/38
M117
Mk. 62
Mk. 82/84
Production
Built23170193102
Total744
