Preceded by:
County (1962)Succeeded by:
Sheffield (Type 42) (1975) | |
| Class | Bristol |
| Type | Guided Missile Destroyer |
| Year | 1973 |
| Crew | 407 |
| Dimensions | |
| Length | 149.3 m (pp) 154.3 m |
| Beam | 16.8 m |
| Draught | 6.8 m |
| Displacement | |
| Empty | 6,700 t |
| Loaded | 7,700 t |
| Performance | |
| Speed | 56 km/h |
| Range | 9,260 km @ 33 km/h |
| Machinery | |
| Shafts | 2 |
| Turbines | 2 x Geared steam 30,000 hp Standard Range 2 x Gas turbine 44,000 hp Rolls-Royce Olympus TM.IA |
| Boilers | 2 x Babcock & Wilcox |
| Fuel | Oil: 900 t |
| Armament | |
| Main | 1 x 114-mm/55 (1 x 1) 4.5-in Mk. 8 -10° / +55° |
| Anti-Sub | Ikara GWS.40 (1 x 1) Limbo Mk. 10 (305) |
| AA Weapons | Sea Dart GWS.30 (1 x 2) |
| Armor | |
| Armor | None |
| Sensors | |
| Radar | Type 909 Type 965 (AKE-2) Type 978 Type 1006 Type 992/993 |
| Sonar | Type 184 Type 162 |
| Production | |
| Built | 1 |
| Total | 1 |
| Ship | Code | Builder | Laid | Launch | Comm | Decomm | Fate | ||
|
Bristol | D23 | Swan Hunter | 15/11/1967 | 30/06/1969 | 31/03/1973 | 14/06/1991 | Inactive |
