| Class | Atlanta | Juneau | |
| Type | Light Cruiser | Light Cruiser | |
| Year | 1942 | 1946 | |
| Crew | 623 | 623 | |
| Dimensions | |||
| Length | 161.6 m (pp) 1,650.1 m | 161.6 m (pp) 1,650.1 m | |
| Beam | 16.2 m | 16.2 m | |
| Draught | 6.3 m | 6.3 m | |
| Displacement | |||
| Empty | 6,590 t | 6,700 t | |
| Loaded | 8,100 t | 8,450 t | |
| Performance | |||
| Speed | 60 km/h | 60 km/h | |
| Range | 15,742 km @ 28 km/h | 15,742 km @ 28 km/h | |
| Machinery | |||
| Shafts | 2 | 2 | |
| Turbines | 2 x Geared steam 75,000 hp Westinghouse | 2 x Geared steam 75,000 hp Westinghouse | |
| Boilers | 4 x Babcock & Wilcox | 4 x Babcock & Wilcox | |
| Fuel | Oil: 1,360 t | Oil: 1,360 t | |
| Armament | |||
| Main | 16 x 127-mm/38 (8 x 2) 5"/38 Mk. 12 -10° / +35° | 12 x 127-mm/38 (6 x 2) 5"/38 Mk. 12 -10° / +35° | |
| Anti-Aircraft | 16 x 28-mm (4 x 4) 1.1"/75 Mk. 1 16 x 40-mm (8 x 2) Bofors 8 x 20-mm (8 x 1) Oerlikon | 32 x 40-mm (6 x 4, 4 x 2) Bofors 16 x 20-mm (8 x 2) Oerlikon | |
| Torpedo tubes | 2x4 x (21-in) | 2x4 x (21-in) | |
| Broadside | 400 kg | 300 kg | |
| Armor | |||
| Belt | 95 mm | 95 mm | |
| Bulkhead | 95 mm | 95 mm | |
| Deck | 32 mm | 32 mm | |
| Gun turret | 25 - 32 mm | 25 - 32 mm | |
| Machinery | 28 - 95 mm | 28 - 95 mm | |
| Conning tower | 64 mm | - | 0 mm |
| Sensors | |||
| Radar | SC SG Mk. 12/22 | SC SG Mk. 12/22 | |
| Production | |||
| Built | 8 | 3 | |
| Total | 11 |
| Ship | Code | Builder | Laid | Launch | Comm | Decomm | Fate | ||
|
Atlanta † | CL-51 | Federal Shipbuilding | 22/04/1940 | 06/09/1941 | 24/12/1941 | 13/11/1942 | † | Loss by surface ship |
|
Juneau † | CL-52 | Federal Shipbuilding | 27/05/1940 | 25/10/1941 | 14/02/1942 | 13/11/1942 | † | Loss by submarine |
|
San Diego | CL-53 | Bethlehem Steel | 27/03/1940 | 26/07/1941 | 10/01/1942 | 04/11/1946 | Sold/Scrapped | |
|
San Juan | CL-54 | Bethlehem Steel | 15/05/1940 | 06/09/1941 | 28/02/1942 | 09/11/1946 | Sold/Scrapped | |
|
Oakland | CL-95 | Bethlehem Steel (SF) | 14/07/1941 | 23/10/1942 | 17/07/1943 | 01/07/1949 | Sold/Scrapped | |
|
Reno | CL-96 | Bethlehem Steel (SF) | 01/08/1941 | 23/12/1942 | 29/12/1943 | 04/11/1946 | Sold/Scrapped | |
|
Flint | CL-97 | Bethlehem Steel (SF) | 23/10/1942 | 25/01/1944 | 31/08/1944 | 06/05/1947 | Sold/Scrapped | |
|
Tucson | CL-98 | Bethlehem Steel (SF) | 23/12/1942 | 02/09/1944 | 03/02/1945 | 11/06/1949 | Sold/Scrapped | |
| Atlanta (Juneau): | |||||||||
|
Juneau | CL-119 | Federal Shipbuilding | 16/09/1944 | 15/07/1945 | 15/02/1946 | 23/07/1955 | Sold/Scrapped | |
|
Spokane | CL-120 | Federal Shipbuilding | 15/11/1944 | 22/09/1945 | 17/05/1946 | 27/02/1950 | Sold/Scrapped | |
|
Fresno | CL-121 | Federal Shipbuilding | 02/12/1945 | 03/05/1946 | 27/11/1946 | 17/05/1949 | Sold/Scrapped | |
