Medium Bomber (1941)

Yermolayev

Yer-2

Yer-2

Designed by V. G. Yermolayev to replace the Il-4, the Yer-2 was a very effective gull winged bomber with twin tail fins which was unfortunately produced in very few numbers despite highly satisfactory performance figures. Featuring an offset cockpit as one of its most prominent features, the attractive Yer-2 was capable of impressive range and it is said to have bombed Berlin in various occasions during nighttime raids, an astonishing feat considering it was only a twin-engined aircraft. Its low production therefore was mostly due not to lack of appeal but rather due to the lack of importance attached to strategic bombing by Soviet authorities during the conflict and which had the Yer-2 end up performing mostly short-range attacks behind the front lines with a small number converted to VIP transports. Following Yermolayev's death in 1944, his bureau was inherited by Sukhoi.

The Yer-2 originated as a derivative of the STAL-7 transport, its prototype was known as the DB-240 and had its maiden flight in June 1940. There were no major combat variants other than the basic Yer-2 although some aircraft were eventually fitted with ASh-30B engines in addition to other improvements such as a revised cockpit, increased armamanet and heavier payloads. Two aircraft were converted to VIP transports and designated Yer-2ON.

Preceded by:

None

Succeeded by:

None

Datafile

DesignYer-2Yer-2bis
TypeMedium BomberMedium Bomber
Year19411943
Crew44
Dimensions
Length16.40 m16.40 m
Height4.820 m4.820 m
Wing Span23 m23 m
Wing Arean/an/a
Weight
Empty7,070 kg10,340 kg
Loaded12,520 kg14,250 kg
Maximum0 kg18,580 kg
Wing Loading0 kg/m²254.2 kg/m²
Performance
Speed437 km/h420 km/h
Speed S/L?370 km/h
Ceiling7,700 m7,200 m
Range4,000 km5,500 km
Powerplant
Engine2 x M-105
Klimov
783 kW
2 x ACh-30B
Charomskiy
1,119 kW
Fuel Loadn/a5,460 kg
Thrust/Weight0.270.26
Armament
Guns3 x 12.7-mm
UBT (705)
1 x 20-mm
ShVAK (200)
2 x 12.7-mm
UBT (470)
x
Payload4,000 kg5,000 kg
AS WeaponsFAB-100/250/500/1000
FAB-100/250/500/1000
Production
Built128n/a
Total430
