Air Weapons

Fighter (1940)

Westland

Whirlwind

Whirlwind
Whirlwind

A number of aircraft were designed as possible successors to the Spitfire and Hurricane, the least successful of which was the Westland Whirlwind, a rather unconventional twin-engine day fighter which was the first of such configuration to be fielded by the RAF. In spite of a fairly decent top speed and packing a very powerful punch with four nose-mounted cannon, the Whirlwind suffered from inadecuate engines which hampered its performance overall as well as difficult maintenance and high landing speeds which proved highly inconvenient in early-war airfields. Only two squadrons received the Whirlwind, and it was in service only up to 1941 although later it was used as a fighter-bomber (nicknamed the "Whirlybomber") in cross-Channel strikes against occupied Europe. These would serve until 1943 upon which they were retired from front-line duties.

The prototype Whirlwind first flew on 11 October 1939 and entered service in June of the following year. The Mk. I variant was the original fighter version while its conversion to a fighter-bomber was designated Mk. IA with underwing bomb racks. No other variants besides these were produced.

Preceded by:

None

Succeeded by:

None

Datafile

DesignWhirlwind Mk. IA
TypeFighter-Bomber
Year1940
Crew1
Dimensions
Length9.98 m
Height3.531 m
Wing Span13.72 m
Wing Arean/a
Weight
Empty3,769 kg
Maximum5,176 kg
Wing Loading222.8 kg/m²
Performance
Speed579 km/h
Ceiling9,235 m
Range1,287 km
Powerplant
Engine2 x Peregrine I
Rolls-Royce
660 kW
Thrust/Weight0.43
Armament
Guns4 x 20-mm
Hispano Mk. I
Payload454 kg
Production
Built112
Total114
