Vickers

VC10

VC10
VC10

It is not uncommon for airliners to be converted for military use and the Vickers VC10 was no exception. Developed initially as a transport aircraft, it was later also used as a tanker and remains in service today in that role with the RAF ending up possessing all surplus airliners for conversions and spares. Superficially there is little difference between the airliner and military versions, the most noticeable ones being a large cargo door, different cabin configurations (for dual-role passenger/freight or full-freight use), and an APU in the tail. Likewise, the tankers are fitted with either double or triple (depending on variant) hose-and-drogue inflight-refuelling units and can also be refuelled themselves via a permanently placed probe in the nose. Although nearing the end of their service life, RAF VC10s will continue to be used until possibly replaced by the A330 MRTT.

The civilian prototype of the VC10 was first flown on 29 June 1962, two years after the RAF had issued a specificiation for a strategic transport which is was eventually to fulfill. Service deliveries of the VC10 C.1 began in 1965 and featured the improved engines of the Super VC10 airliner. These were eventually converted to tankers and redesignated VC10 C.1K reflecting their dual role. Newer versions, however, were converted directly as tankers and known as the VC10 K.2, K.3 and K.4 of which the last two remain in service today. These feature three hose-and-drogue units unlike the C.1K which had two.

Preceded by:

None

Succeeded by:

Voyager (2011)

Datafile

DesignVC10 C.1VC10 K.3
TypeTransportTanker
Year19661985
Crew44
Dimensions
Length48.36 m52.32 m
Height12.040 m12.040 m
Wing Span44.55 m44.55 m
Wing Arean/an/a
Weight
Empty66,225 kg71,938 kg
Maximum100,000 kg100,000 kg
Wing Loading367.1 kg/m²367.1 kg/m²
Performance
Speed935 km/h935 km/h
Ceiling12,802 m12,802 m
Range6,273 km7,596-11,474 km
Powerplant
Engine4 x Conway Mk. 301
Rolls-Royce
9,888 kgf
4 x Conway Mk. 550B
Rolls-Royce
9,888 kgf
Thrust/Weight0.540.50
Armament
Guns--
Payload26,036 kg27,361 kg
Production
Built144
Total28
