Air Weapons

Fighter (1941)

Reggiane

Re.2001/2002 Ariete

Re.2001/2002 Ariete
Re.2001/2002 Ariete

Not to be left behind by rivals Macchi and Fiat, Reggiane upped the ante with the Re.2001 Ariete (Ram), a very effective mid-war design based on its earlier Re.2000 fighter. Sporting a license-produced Daimler-Benz DB 601A and a redesigned wing structure, the Re.2001 was unfortunately never awarded production priority over its superior contemporary, the MC.202 Folgore although it was used to some extent as a night fighter and for homeland defense. Undaunted, Reggiane eventually mated the Re.2001 with an indigenous Piaggio radial engine and the result was the superb Re.2002 Ariete II, Italy's finest fighter-bomber of the war. It was so good that the Luftwaffe planned to develop a version with the Fw 190 engine but eventually settled with using all captured and newly produced units for its own, flying it primarily for ground attack missions against partisans in occupied France.

The first flight of the prototype Re.2001 was in July 1940, with planes first delivered for service in June of the following year. Variants included the Re.2001CB fighter-bomber and the Re.2001CN night fighter which was used extensively during the last year before the Italian surrender. The Re.2002, on the other hand, first flew just three months after its predecessor but did not enter squadron service until early 1942. It nevertheless saw widespread production and use after the surrender, mostly by the Luftwaffe.

Preceded by:

None

Succeeded by:

None

Datafile

DesignRe.2001Re.2002
NameAriete IAriete II
TypeFighterFighter-Bomber
Year19411942
Crew11
Dimensions
Length8 m8.16 m
Height3.200 m3.150 m
Wing Span11 m11 m
Wing Arean/an/a
Weight
Empty2,070 kg2,390 kg
Maximum3,280 kg3,240 kg
Wing Loading160.8 kg/m²158.8 kg/m²
Performance
Speed540 km/h530 km/h
Ceiling12,000 m10,500 m
Range1,040 km1,100 km
Powerplant
Engine1 x RA.1000 RC 41
Alfa Romeo
876 kW
1 x P.XIX RC 45
Piaggio
876 kW
Thrust/Weight0.520.45
Armament
Guns2 x 12.7-mm
2 x 7.7-mm
2 x 12-7-mm
2 x 7.7-mm
Payload640 kg950 kg
Production
Built252224
Total476
