P-2 Neptune

P-2 Neptune

Lockheed's long line of successful land-based maritime patrol aircraft continued post-war with the remarkable P-2 Neptune which served for over three decades with the US Navy and even more with various other countries which adopted it. The attractive P-2 was designed as a replacement for the Ventura and Harpoon aircraft which had been used during World War II and in contrast to its predecessors, was built from the start to perform in its maritime role as an attractive two-engine mid-wing design which also included a tricycle undercarriage and radar (later versions also featured two auxiliary turbojets). P-2s not only were used for patrol and ASW duties: proof of their versatility was the conversion into early warning, anti-shipping, interdiction, airborne relay, drone launching, and electronic reconnaissance platforms. With the US they saw considerable use over Korea as well as Vietnam and was exported to 10 other nations including Argentina (which used it during the Falklands War), Australia, Brazil, Canada, Chile, France, the Netherlands, Portugal, the UK, and Japan which license produced an advanced version by Kawasaki. US P-2s were eventually phased out in favor of the P-3 Orion and were fully retired in 1978.

Begun as the Lockheed Model 26, the XP2V-1 had its maiden flight as early as 17 May 1945 and entered service almost exactly two years later as the P2V-1. Its follow-ups were the P2V-2 with a solid nose armed with cannons, the P2V-3 with provision for underwing rockets, the P2V-4 (redesignated P-2D after 1962) with new engines, wingtip fuel tanks, and sonobuoys as well as an improved radar. A significant upgrade to the Neptune began with the P2V-5 (P-2E) which was the first to be built in large numbers. It had additional fuel capacity, extra sensors and equipment, and the inclusion of auxiliary turbojet engines in what would become the P2V-5F (P-2F). Later, the P2V-6 for minelaying and torpedo attack duties as well as reconnaissance and was also known as the P2V-6F (P-2G) with the extra turbojets. The final patrol version for the USN was the P2V-7 (P-2H) with a new bulged canopy and a MAD boom. Other versions built in limited numbers were the P2V-3W early warning variant, the AP-2E for Sigint/Elint duties, the AP-2H gunship conversion, and the RB-69A for aerial reconnaissance. Foreign versions included the Neptune MR.1 for the UK, the CP-122 for Canada, and the Japanese-built PV2-Kai (P-2J) with numerous improvements over US versions and with subvariants including the EP-2J Elint platform and the UP-2J for target towing and ECM training.

Preceded by:

None

Succeeded by:

None

Datafile

DesignP2V-2P-2HP-2J
NameNeptuneNeptuneNeptune
TypeMaritime PatrolMaritime PatrolMaritime Patrol
Year194719541969
Crew9-107-910-12
Dimensions
Length23.72 m27.94 m29.21 m
Height8.560 m8.941 m8.928 m
Wing Span30.48 m31.65 m30.87 m
Wing Arean/an/an/a
Weight
Empty15,404 kg19,509 kg19,278 kg
Maximum28,613 kg36,288 kg34,020 kg
Wing Loading308.0 kg/m²390.6 kg/m²366.2 kg/m²
Performance
Speed515 km/h586 km/h649 km/h
Ceiling7,925 m6,828 m9,144 m
Range6,405 km7,000 km4,448 km
Powerplant
Engine2 x R-3350-24W
Wright
2,088 kW
2 x R-3350-32W
Wright
2,759 kW
2 x T64-IHI-10
Ishikawajima
2,125 kW
Thrust/Weight0.330.340.27
Sensors
Radar-AN/APS-20
AN/APS-80
Armament
Guns4 x 20-mm
2 x .50-in
--
Payload3,629 kg3,629 kg3,629 kg
Production
Built8131182
Total1,181
P-2H: 2 x 3,400-lb (1,542-kg) Westinghouse J34-WE-34 auxiliary turbojet; P-2J: 2 x 3,086-lb (1,400-kg) Ishikawajima J3-IHI-7C auxiliary turbojet
