Air Weapons

Anti-Submarine (1965)

Kamov

Ka-25 'Hormone'

Ka-25 'Hormone'

The advent of ballistic-missile submarines during the 1950s immediately prompted the development of a capable helicopter anti-submarine platform capable of operating from the USSR's growing number of surface warships. The result was the Kamov Ka-25 'Hormone' which soon became a fixture of the Soviet navy after initial operation from the Moskva-class helicopter carriers. The Ka-25 is characterized by twin turboshaft engines driving two coaxial contra-rotating propellers, thus eliminating the need for a tail rotor, and features a search radar on a prominent undernose bulge as well as dipping sonar and the ability to carry guided torpedoes. A number were also equipped for the electronic warfare role and as a search and rescue (SAR) or utility helicopter. Foreign users included India, Syria, Vietnam and Yugoslavia while in Russian service it was slowly replaced by the Ka-27.

What began as the Ka-20 'Harp' prototype was first spotted in July 1961 and was later recognized in service as the Ka-25K civil flying crane. The initial ship-based variant was known as the Ka-25BSh 'Hormone-A' while other developments included the Ka-25T 'Hormone-B' electronic warfare helicopter (with the ability to provide target acquisition and mid-course guidance for ship-launched cruise missiles) and the Ka-25PS 'Hormone-C' SAR and utility helicopter which is similar to the Ka-25BSh but with all non-essential equipment removed.

Preceded by:

None

Succeeded by:

Ka-27/29 'Helix' (1982)

Datafile

DesignKa-25BSh
Code NameHormone-A
TypeAnti-Submarine
Year1965
Crew2
Dimensions
Length9.75 m
Height5.370 m
Rotor Diameter
Rotor Disc Area
Wing Span15.74 m
Wing Arean/a
Weight
Empty4,765 kg
Maximum7,500 kg
Wing Loading19.3 kg/m²
Performance
Speed209 km/h
Ceiling3,500 m
Range400 km
Powerplant
Engine2 x GTD-3F
Glushenkov
671 kW
Thrust/Weight0.34
Sensors
RadarBig Bulge
Armament
Guns-
Payload600 kg
AS WeaponsE45-75A
Production
Builtn/a
Total460
