JH-7 'Flounder'

JH-7 'Flounder'
JH-7 'Flounder'

The Xian JH-7 'Flounder' (also known as the FCB-1 Flying Leopard) is China's first purpose-built fighter-bomber which began as two separate requirements for the PLANAF and PLAAF. In the event, the PLAAF version with side-by-side cockpits (similar to the F-111 and Su-24) was abandoned while the naval version with more conventional tandem layout went ahead. The JH-7 was also planned to be equipped with a reverse-engineered versión of the Rolls-Royce Spey engine, unfortunately problems with this undertaking meant that the aircraft would be delayed for a number of years entering service only until the early 90s (and with the PLAAF even later). Overall the JH-7 is a fairly decent naval strike aircraft albeit underpowered and with a smaller payload than other similar aircraft like the Tornado, factors which may limit its use given the recent introduction of more capable aircraft like the J-10 and J-11.

The maiden flight of the JH-7 was on 14 December 1988 and entered service exclusively with the PLANAF in 1994 although production was minimal due to engine problems. A major improvement resulted in the JH-7A, these include additional Spey engines purchased from the UK as well as the possibility of domestic license-production. The JH-7A also features an improved avionics set and additional weapons such as laser-guided bombs. An export version is known as the FBC-1 Flying Leopard but has yet to find a suitable customer.

Preceded by:

Q-5 'Fantan' (1970)

Succeeded by:

JF-17 Thunder (2007)

Datafile

DesignJH-7
TypeFighter-Bomber
Year1994
Crew2
Dimensions
Length21 m
Height6.220 m
Wing Span12.80 m
Wing Arean/a
Weight
Emptyn/a
Maximum27,500 kg
Wing Loading?
Performance
SpeedMach 1.7
Ceiling16,000 m
Range3,650 km
Powerplant
Engine2 x WS-9
Xian
9,300 kgf
Thrust/Weight?
Sensors
RadarType 232H
Armament
Guns1 x 23-m
Payload5,000 kg
Hardpoints5
AA WeaponsPL-5
YJ-8
YJ-82
YJ-91
Production
Builtn/a
Total240
