Air Weapons

Medium Bomber (1940)

Ilyushin

Il-4

Il-4

By the time the Germans invaded in 1941, the Ilyushin Il-4 had already been a tried and tested aircraft having flown extensively during the Winter War of 1940. By Russian standards the Il-4 was a strategic bomber albeit much smaller than it's western counterparts which would have considered it a medium bomber instead. It managed to bomb Berlin during the summer of 1941 (the first Soviet aircraft to do so) and was used well up until 1945 and the post-war era even though production had ceased a year earlier. Despite it's good range, the Il-4 was poorly protected and suffered heavy casualties even from mediocre Finnish aircraft like the Gladiator or Fokker D.XXI although this was compensated by its versatility which allowed it to perform roles like glider tug, transport and reconnaissance in addition to maritime duties with Soviet Naval Aviation. A number of captured examples found themselves flown by Finland.

The prototype of this aircraft was designated TsKB-26 and took its maiden flight as early as May 1936 with production commencing in 1937 as the DB-3 with an open cockpit. Production switched shortly after to the DB-3B with a more powerful engines and closed cockpits, later the definitive DB-3F or Il-4 appeared. These featured yet another engine upgrade as well as a redesigned nose and were immediately put into mass production. Due to a shortage of strategic materials, many Il-4s had extensive use of wood in the structure in place of metal parts.

Preceded by:

DB-3 (1936)

Succeeded by:

None

Datafile

DesignDB-3FIl-4
TypeMedium BomberMedium Bomber
Year19401942
Crew44
Dimensions
Length14.79 m14.79 m
Height4.100 m4.100 m
Wing Span21.44 m21.44 m
Wing Arean/an/a
Weight
Empty5,641 kg6,421 kg
Loaded8,000 kg10,055 kg
Maximum10,153 kg12,120 kg
Wing Loading152.2 kg/m²180.9 kg/m²
Performance
Speed435 km/h398 km/h
Speed S/L350 km/h332 km/h
Ceiling10,000 m8,300 m
Range3,300 km3,585 km
Powerplant
Engine2 x M-88
Tumansky
820 kW
2 x M-88B
Tumansky
820 kW
Thrust/Weight0.350.31
Armament
Guns3 x 7.62-mm
ShKAS (2,050)
1 x 12.7-mm
UBT (230)
2 x 7.62-mm
ShKAS (1,500)
Payload2,500 kg2,500 kg
Production
Builtn/an/a
Total5,256

Gallery
