Air Weapons

Close Support (1941)

Ilyushin

Il-2

Il-2
Il-2

Powerful and rugged, the Ilyushin Il-2 was the most widely produced aircraft in history with over 36,000 built. It epitomized the Soviet need for ground attack aircraft and earned a variety of nicknames: the Germans called it "Schwarztot" (Black Death) and the "concrete bomber", those who flew it called it the "flying tank" or most commonly, the Sturmovik (Attacker). The Il-2 offered unprecedented armor protection to compensate for a rather slow speed and was able to carry bombs, rockets and even torpedoes, as well as mounting anti-tank guns; still it was somewhat vulnerable to enemy fighters although this would be less of a concern once the Soviets obtained air superiority after 1943. Used extensively during the full course of the Russian campaign, Il-2 pilots developed some innovative tactics like the "Circle of Death" in which Il-2 would cross a target from the side, turn and attack from behind: during the Battle of Kursk, the 9th Panzer Division suffered 70 knocked out tanks from this. Without a doubt the Il-2 was one of the best ground-attack aircraft of the war and served up until the fall of Berlin by which time it was in the process of being replaced by the Il-10 although it remained in use post-war by various Eastern European nations, China, and North Korea.

The Sturmovik first flew in prototype form as the TsKB-57 on 12 October 1940 and a limited number of the basic Il-2 variant were already available when the Germans invaded in June 1941. A heavily modified variant was introduced the following year, known as the Il-2m3 it featured a second crew member manning a gun for rear defense and a boosted engine. Later, the Il-2m3(mod) was modified to carry 37-mm guns in place of the 23-mm cannon while the Il-2T became a dedicated torpedo bomber. Despite the enormous number of aircraft built, no other major variants were produced although the similar looking follow-up, the Il-10, was based on the same design but is described separately.

Preceded by:

None

Succeeded by:

Il-10 (1945)

Datafile

DesignIl-2Il-2MIl-2M3
Code NameBarkBarkBark
TypeClose SupportClose SupportClose Support
Year194119421943
Crew122
Dimensions
Length11.65 m11.65 m11.65 m
Height3.400 m3.400 m3.400 m
Wing Span14.60 m14.60 m14.60 m
Wing Arean/an/an/a
Weight
Empty4,261 kg4,525 kg4,625 kg
Loaded5,788 kg6,060 kg6,160 kg
Maximum5,988 kg6,260 kg6,360 kg
Wing Loading155.5 kg/m²162.6 kg/m²165.2 kg/m²
Performance
Speed414 km/h411 km/h390 km/h
Speed S/L380 km/h370 km/h375 km/h
Ceiling6,200 m6,000 m6,000 m
Range740 km685 km685 km
Powerplant
Engine1 x AM-38
Mikulin
1,238 kW
1 x AM-38
Mikulin
1,238 kW
1 x AM-38F
Mikulin
1,305 kW
Thrust/Weight0.350.330.34
Armament
Guns2 x 20-mm
ShVAK (420)
1 x 7.62-mm
ShKAS (1,500)
2 x 20-mm
ShVAK (420)
1 x 12.7-mm
UBS (300)
2 x 7.62-mm
ShKAS (1,500)
2 x 23-mm
VYa-23 (300)
1 x 12.7-mm
UBS (300)
2 x 7.62-mm
ShKAS (1,500)
Payload600 kg600 kg600 kg
Hardpoints222
AS WeaponsFAB-50/100/250
RS-82 (8)
RS-132 (4)
FAB-50/100/250
RS-82 (8)
RS-132 (4)
FAB-50/100/250
PTAB
RS-82 (8)
RS-132 (4)
Production
Builtn/an/an/a
Total35,952
