Fighter-Bomber (1946)

de Havilland

Hornet

Hornet

Built as a replacement for the legendary Mosquito, the de Havilland Hornet began life as a private venture to improve on its predecessor as a high-performance twin engined strike figher. Like the Mosquito, the Hornet was built extensively of wood although the wing also featured metal parts and upon its first flight achieved speeds superior to those of even the initial Meteor jets. Given its wartime design, the Hornet was intended for long range operations in the Pacific but entered service too late to see action. Instead it was used by Fighter Command and later by the Far Eastern Air Force to combat Malayan communists, replacing older Spitfires and Beaufighters in the ground attack role. A navalized development was known as the Sea Hornet and was used additionally at sea as a photo-reconnaissance platform and a night-fighter. RAF Hornets were ultimately replaced by Vampires while naval versions flew until 1955.

Design of the DH.103 began in 1942 with the maiden flight occurring on 28 July 1944. Initial deliveries began with the Hornet F.1 for the RAF followed by the F.3 major production version with increased fuel capacity and underwing hardpoints. Other RAF variants included the PR.2 photo-reconnaissance aircraft and the similar but armed F.4. Naval versions began with the Sea Hornet F.20 and also included the NF.21 night fighters with ASH radar in a nose radome and the PR.22 photo-recon platform.

Preceded by:

None

Succeeded by:

None

Datafile

DesignHornet F.3Sea Hornet NF.21
TypeFighter-BomberNight Fighter
Year19461949
Crew12
Dimensions
Length11.18 m11.28 m
Height4.318 m4.318 m
Wing Span13.72 m13.72 m
Wing Arean/an/a
Weight
Empty5,842 kg6,455 kg
Maximum9,553 kg8,859 kg
Wing Loading284.8 kg/m²264.1 kg/m²
Performance
Speed760 km/h692 km/h
Ceiling11,430 m11,125 m
Range4,820 km2,414 km
Powerplant
Engine2 x Merlin 130/131
Rolls-Royce
1,544 kW
2 x Merlin 133/134
Rolls-Royce
1,514 kW
Thrust/Weight0.640.57
Sensors
Radar-ASH
Armament
Guns4 x 20-mm
Hispano Mk. V
4 x 20-mm
Hispano Mk. V
Payload907 kg907 kg
Hardpoints22
Production
Built13278
Total391
