Fighter (1940)

Dewoitine

D.520

D.520
D.520

Far and away the finest French fighter of World War II, the Dewoitine D.520, in the hands of a good pilot, was good enough hold its own against the Bf 109E. However, the D.520 was also perhaps the best example of the French aircraft industry's failure to provide the Armée de l'Air with sufficient numbers of good designs: only 36 of these were available when the Blitzkrieg was launched upon the West and only through a massive and unprecedented production effort was a record number of 10 D.520's a day churned out after that. Unfortunately it was too little and too late, and despite a favorable kill ratio, not enough were serviced to tilt the balance of the air war. Overall, the D.520 was living evidence of what could have been accomplished had the French aircraft industry been properly organized before the war, nevertheless production continued in Vichy France and was eventually also used by various Axis air forces. Not surprisingly therefore, the highest-scoring French pilot of the Armée de l'Air, Pierre Le Gloan, shot down a total of 18 enemy aircraft with the D.520.

The D.520 prototype was first flown on 2 October 1938 but the first production aircraft flew over one year later when the war had already started. Many of the surviving D.520s were taken up by Vichy forces in France and Africa where over 400 were in service. On the drawing board were various additional varianst such as the Rolls-Royce Merlin-powered D.521 and the D.524 with Hispano-Suiza 12Z engines but neither of these ever entered production.

Preceded by:

None

Succeeded by:

None

Datafile

DesignD.520
TypeFighter
Year1940
Crew1
Dimensions
Length8.76 m
Height2.560 m
Wing Span10.20 m
Wing Arean/a
Weight
Empty2,090 kg
Maximum2,780 kg
Wing Loading174.3 kg/m²
Performance
Speed529 km/h
Ceiling11,000 m
Range1,250 km
Powerplant
Engine1 x 12Y-45
Hispano-Suiza
506 kW
Thrust/Weight0.29
Armament
Guns1 x 20-mm
4 x 7.5-mm
Payload-
Production
Built915
Total918
