Air Weapons

Transport (1956)

Fairchild

C-123 Provider

C-123 Provider
C-123 Provider

Orignally designed as an assault glider for the USAF the Fairchild C-123 Provider was a widely utilized medium transport which was capable of operating in short or unprepared airstrips. The C-123 had a rather turbulent development history: it was first conceived by Chase Aircraft and later taken over by famed industrialist Henry Kaiser before political issues ended up assinging the project to Fairchild. Still, the conventional high-wing C-123 became a highly valued asset during the Vietnam War where it obtained distinction for its ruggedness and reliability. In that conflict they were used mostly as troop and cargo carriers but also as night attack gunships and, most notoriously, as defoliant sprayers carrying the controversial Agent Orange. C-123 remained on hand until the 1980s with ANG units and some being used up to today by small freight companies. Other operators inlcuded Cambodia, El Salvador, Laos, the Philippines, Saudi Arabia, South Korea, South Vietnam, Taiwan, Thailand, and Venezuela.

The original prototype XG-20 glider would eventually lead to the XC-123, first flown on 14 October 1949. Production orders followed for the first C-123B units. It was then decided to add auxiliary turbojets beginning with the C-123J (Fairchild J-44s) and later the C-123K (GE J85s). Other variants included the HC-123B rescue platform for the USCG, the UC-123B and K defoliant sprayers, the NC-123B flare ship for night operations, and the AC-123K (or NC-123K) attack gunship with a lengthened nose housing forward looking infrarer (FLIR) sensors, laser rangefinders, and could drop cluster bombs.

Preceded by:

None

Succeeded by:

None

Datafile

DesignC-123K
NameProvider
TypeTransport
Year1966
Crew3
Dimensions
Length23.09 m
Height10.363 m
Wing Span33.53 m
Wing Arean/a
Weight
Empty16,028 kg
Maximum27,216 kg
Wing Loading239.5 kg/m²
Performance
Speed394 km/h
Ceiling7,620 m
Range2,366 km
Powerplant
Engine2 x R-2800-99W
Pratt & Whitney
1,715 kW
Thrust/Weight0.26
Armament
Guns-
Payload10,886 kg
Production
Built183
Total311
C-123K: 2 x 2,850-lb (1,293-kg) General Electric J85-GE-17 auxiliary turbojet
