Air Weapons

Bomber (1961)

North American

A-5 Vigilante

A-5 Vigilante
A-5 Vigilante

Although it received little attention, the North American A-5 Vigilante was a highly efficient supersonic bomber for the US Navy at a time when said service still maintained strategic bombing capability. Intended as an all-weather attack bomber, the Vigilante was significant for being the first major combat aircraft with variable geometry intakes, multi-mode radar, a digital computer, and slab tailplanes instead of the more conventional ailerons thus giving it a decidedly modern apperance more akin to a fourth generation aircraft than those in its time. Unfortunately for such an advanced aircraft, it entered service just as the USN was relinquishing its strategic bomber role and thus, it saw action in the Vietnam War mostly as a reconnaissance platform. After the war, most were retired due to their expense and complexity with the last units in USN service until 1979.

Maiden flight of the XA3J-1 took place on 31 August 1958 and it entered service as the A3J-1 (A-5A after 1962) two years later. The A3J-2 (A-5B) included additional fuel in a dorsal saddle tank, and additional underwing hardpoints; it was the last bomber version built. Finally, a reconnaissance variant was the A3J-3P (RA-5C) which included new builds as well as conversions of A-5A and B units.

Preceded by:

A-3 Skywarrior (1956)

Succeeded by:

None

Datafile

DesignA-5A
NameVigilante
TypeBomber
Year1961
Crew2
Dimensions
Length23.32 m
Height5.918 m
Wing Span16.15 m
Wing Arean/a
Weight
Empty14,833 kg
Maximum28,554 kg
Wing Loading407.6 kg/m²
Performance
SpeedMach 2.0
Ceiling15,880 m
Range2,076 km
Powerplant
Engine2 x J79-GE-8
General Electric
7,711 kgf
Thrust/Weight0.95
Armament
Guns-
Payload?
Hardpoints2
AA WeaponsMk. 27/28/43
Mk. 83/84
Production
Built57
Total144

Gallery
